Rays Twinaxial Cable RS 429 Cable
Product Introduction：
The aviation RS 429 data bus cable employs fluoroplastic insulation and sheathing, featuring high- and low-temperature resistance, aging resistance, corrosion resistance, flame retardancy, lightweight, small outer diameter, and excellent mechanical toughness. It ensures stable performance and maintains constant signal propagation speed across a wide frequency range.It is primarily used in aviation electronic systems, AFDX aircraft data networks, and military communication data networks.
This product is a direct replacement for Belden 8380, MOGAMI W2997 and TE Connectivity ARINC 429.
Structural Parameters：
| Specification | Maximum Outer Diameter （mm） | Maximum Weight (g/m) |
| 1×2×24A | 3.8 | 23 |
Performance Index：
| Product | Parameters |
| Rated Voltage | ≤600V |
| Rated Operating Temperature | -65℃~200℃ |
| Inner DC Resistance (20℃) | ≤9.38Ω100m |
| Unbalance of Inner Conductor DC Resistance | ≤5.0% |
| Withstand Voltage | 2500V/1min |
| Characteristic Impedance | 77±7 Ω |
| Attenuation（1MHz） | ≤4.59dB/100m |
| Minimum Bending Radius | 6×Cable Outer Diameter |
