RaysTwinaxial Cable-Can cable
Product Introduction：
CAN bus is a serial multi-master controller area network bus. It features high network safety, communication reliability and real-time performance, with simple structure, practicality and low network cost. It is widely applied in automotive computer control systems, as well as industrial environments with harsh conditions, strong electromagnetic interference and severe vibration.
Structural Parameters：
| Specification | Max. OD （mm） | Nominal Insulation OD(mm) | Earth wire | shield | Minimum Sheath Thickness(mm) | Max. Finished OD(mm) | Reference Weight(kg/km) |
| 1×2×0.5 | 1.05 | 2.6 | Tinned Copper | Aluminum-Plastic Composite Film | 0.7 | 7.5 | 92 |
| 1×2×0.22 | 0.65 | 1.7 | Tinned Copper | Aluminum-Plastic Composite Film | 0.7 | 6.6 | 55 |
Performance Index：
| Product | Parameters |
| Rated Operating Temperature | -40℃~105℃ |
| Characteristic Impedance | 120Ω |
| CMRR | ≥ 60 dB |
| Data rate | 8 Mbps |
